EMP Centauri 22khz Switch

EMP Centauri Ltd. is one of the largest European producers of multi-switches, coaxial switches and related accessories for reception and distribution of satellite TV signals. Their highly skilled development staff builds on more than ten year tradition of being in satellite business. Due to unique technology and design of their products you can enjoy quality reception for reasonable price.

EMP Centauri products are manufactured from the latest components on the state-of-the-art SMD automatic production line and the company processes are ISO 9001 certified.

WARRANTY: EMP Centauri guarantees its products will be free from defects in material and workmanship under conditions of normal use. If any of the EMP Centauri products is found to be defective in two years from the manufacture date which is legibly marked on the product, EMP Centauri will repair or replace it. This warranty however does not apply to products which have been modified or disassembled by the buyer after delivery. EMP Centauri reserves the right to make changes in design without prior notice.

Beware of unauthorized dealers selling cloned EMP switches.

Model: S. 162-CW (2 in - 1 Out)

DiSEqC 2.0 2in/1out switch. The inputs are controlled by the Write N0 “Position” command or by Tone Burst. It allows connection of 2 satellite dishes to one satellite receiver, and is going through for 22 kHz and DiSEqC signals. Comes with weatherproof housing. After installation it is necessary to slide a waterproof sleeves over the connector joints. The sleeves are delivered with the switch.

(ANY 2 Satellites to 1 FTA Receiver)

Important Notes:

We have only tested this switch for FTA receivers.
We have not tested this switch with Dish Pro LNBFs. (Any LNBFs with built-in switch may not work.)
When connecting/disconnecting receivers, you MUST unplug the receivers, otherwise switch can be shorted.

Specifications of S. 162-CW
Frequency Range	5-2300 MHz
Control	DiSEqC command “Position” or Tone Burst
Insertion Loss	3 dB avg.
Isolation	35 dB avg.
Current Drawn	30 mA
Dimensions (w,d,h [cm])	6.5 x 7.3 x 4.2
Temperature range	–40°C - +60 °C

Details


SKU	EMP-22KHZ
Price:	CA$24.99
